Sepmaster 2000 Gas Chromatograph

Features:

\\n
• High precision, Multi-function, connects the international advanced technology
\\n
• Unique design sampling system, can lower detection limit
\\n
• Can be installed hydrogen flame ionization detector (FID), pool thermal conductivity detector (TCD), electron capture detector (ECD), flame photometric detector (FPD), nitrogen and phosphorus detector (NPD), photoelectric ionization detector (PDHID) of six kinds of detector.
\\n
•  Thermal conductivity cell detector (TCD) stable time: ≤10 min
\\n

Specifications:

\\n
• LOD(limit of detection): ≤5×10-12g/s   [n-C16]
\\n
• drifting: ≤5×10-13A/30min
\\n
•  noise: ≤2×10-13A
\\n
• linear dynamic range : ≥107
\\n
• thermal conductivity cell detector(TCD)
\\n
• The maximum control temperature: 400???
\\n
• sensitivity: ≥10000mv.ml/mg   [n-C16]
\\n
• drifting: ≤100uV/30mi
\\n
• noise: ≤20uA
\\n
• linear dynamic range: ≥105
\\n
• Electron capture detector(ECD)
\\n
• The maximum control temperature: 350???
\\n
• LOD(limit of detection): ≤6×10-15 g/ml    (γ-666)
\\n
• drifting: ≤50uV/30min
\\n
• noise: ≤20uV
\\n
• linear dynamic range: ≥104
\\n
• Flame photometric detector(FPD)
\\n
• The maximum control temperature: 400???
\\n
• LOD(limit of detection):  ≤2×10-13g/s(P)     ≤5×10-11g/s(S)
\\n
• drifting:  ≤4×10-11A/30min
\\n
• noise:  ≤2×10-12A
\\n
• linear dynamic range:   ≥103(P)      ≥102(S)
\\n
• Nitrogen and phosphorus detector(NPD)
\\n
• The maximum control temperature: 400???
\\n
• LOD(limit of detection): ≤5×10-13g/s(P)       ≤1×10-12g/s(N)
\\n
• drifting: ≤25×10-12A/30min
\\n
• noise: ≤4×10-13A
\\n
• linear dynamic range: ≥103(P)
\\n
• Photoelectric ionization detector(PDHID)
\\n
• LOD(limit of detection): ≤5ppb
\\n
• Application
\\n
• Petroleum, chemical, food, pharmaceutical, environmental protection, for disease control and prevention, safety, water, electricity, metallurgy, scientific research institutes, quality inspection department.
